Home Energy Storage System

FLEXIBLE CONFIGURATION

Battery reverse connection and leakage current protection.

Support anti-backflflow function

Multiple overvoltage, overcurrent and short circuit protection.

STYLISH AND ELEGANT

Stylish appearance, light and simple.

Natural cooling, quiet.

IP65 protection grade, wall-mounted design, save space.

Model		SC HF 3500-24		SC HF 5500-48
Rated power		3500VA/3500W		5500VA/5500W
Input
Voltage		230VAC
Voltage range		170-280VAC(uitable for personal computers) 90-280VAC(Suitable for household appliances)
Frequency range		50Hz/60Hz(Automatic adaptation)
Output
Grid voltage regulation (battery mode)		230VAC±5%
Surge power		6000VA		11000VA
Efficiency		>93.6%
Switch time		10ms
Waveform		Pure sine wave
Battery
Battery voltage		24VDC		48VDC
Float charge voltage		27VDC		54VDC
Overcharge protection		33VDC		63VDC
PV Charge &AC Charge
PV maximum open circuit voltage		500VDC		500VDC
PV maximum power		5500W		5500W
Maximum grid charge current		15A		25A
MPPT operating voltage range		120VDC-450VDC		120VDC-450VDC
PV maximum charge current		25A		25A
Physical properties
Size		300*110*462
Net weight (kg)		9		10
Communication interface		RS232
Environment
Humidity		Relative humidity (non-condensing)
Operating temperature		-10℃-50℃
Storage temperature		-15℃-60℃

Shenzhen CONSNANT Technology Co., Ltd. （simple name: CONSNANT） is a professional manufacturer engaged in research, development and production of UPS (Uninterruptible Power Supply) including the Modular UPS, Outdoor & Indoor UPS,Industrial special UPS, Low Frequency & High Frequency Online UPS and Solar Power System both for home appliance and telecom equipments.
