Comprehensive Protections Solar Power Inverter With LCD + LED Display

Product Categories

Shenzhen Consnant Technology Co., Ltd.

Contact Now

Name: Comprehensive Protections Solar Power Inverter With LCD LED Display
Brand: CONSNANT
Price: 1 USD

Ask Lasest Price
Brand Name :	CONSNANT
Model Number :	CNS600
Certification :	ICE, ISO
Price :	Negotiable
Payment Terms :	T/T, L/C, Western Union
Supply Ability :	1000 pieces per month
Delivery Time :	5-8 days for sample order, 15-21 days for large quantity

Add to Cart

Comprehensive Protections Solar Power Inverter With LCD + LED Display

Features:

FAQ:

Q1: What's included in products?

A: It is included Inverter unit, user manual, cable(optional)

Q2. Your UPS meet CE requirements?

A:Our UPS is with the certificate of CE, ISO and Chinese TLC certificates.

Q3: Can we change the shape, size, color or printing based on the original design?

A: Yes, and OEM, ODM accepted

Q4:. Can you design one specially?

A: Yes

Technical Specifications:

Model NO. Inverter		600	400	1000	1500	2000	3000	4000	5000	6000
Rated Power (W)	400W	600W	800W	1000W	1500W	2000W	3000W	4000W	5000W	6000W
Peak Power (W)	1200W	1800W	2400W	3000W	4500W	6000W	9000W	12000W	15000W	18000W
System Volt.	24V			24V/48V			48V/96V
Inverter Output Volt.	110V/220V±5%							220V ±5%
Output Frequency	50/60Hz±1%
Efficiency	>80%		>85%
Overload Capacity	105-120% 30s; 120*150% 10s; >150% 5s; Short Circuit 10ms
Output Wave	Puse Sine Wave
Solar Charge Controller
Charge Type	MPPT
PV Recommend Power	1500W			1500W/3000W			3000W/6000W
PV Input Volt. Range	35-90V			35~90V(24V)/70-150V(48V)			70-150V(48V)/150-300V(96V)
Input Rate Volt.	40V			40V/102V			102V/170V
Max. Output Current	50A			50A			50A
Floating Charging Volt.	26.80V			53.5V			107V
Equalization Charging Volt.	28.8V			57.6V			115.2V
AC Battery Charger
AC Input Volt.	90~125V (110V) / 180~250V (220V)
Input Frequency	50/60Hz±3%
AC Charge Current	Standard 10A; Max. : 15A
AC By-pass
Transfer Time	<8ms
AC Input Wave Form	AC or Generator (Sine Wave)
General
Display	LCD + LED
Display Content	PV Status; Battery Capacity; AC Input & Output Volt.; Load; Running Status
Cooling Method	Fan Cooling
Communication	RS232 (Optional)
Noise Emission [dB (A)]	<60dB (1m)
Operating Temp. Range	-20~50°C
Storage Temp. Range	-15~70^oC
Operation Humidity	0-90%RH Non-condensing
Dimension (mm)	410x160X210mm			480x190x345mm			480x240x480mm
Weight (KG)	8KG	9KG	10KG	11 KG	19KG	22KG	35KG	40KG	45KG	54KG
